The big question is what wire go's where.On my 97 Jeep Wrangler Sport I wired as follows; First: the graytach wire and magnetic pickup are not used, Second: the heavy red(pos +) and black (neg -) to the battery, the 4 remaining wireswill hook up between the coil-pack plug and harness.Cut the plug off leaving enough wire to attach the street-fire(S/F) wires. So let's start with the plug, my TJ colors are solidGray and Green/Black stripe.Attach the S/F Orange to the Green wire on plug; attach the S/FBlack to the Gray wire and plug it back in the coil.On the harness side attach the S/F White to the Gray wire fromthe harness; attach the S/F Small Red to the Green wire from theHarness.Close the hood and go.
S T R E E T F I R E. W W W. S T R E E T - F I R E. C O M. ( 9 1 5 ) 8 5 7 - 5 2 0 0.
Free Street Fire Racing Videos
Msd Street Fire Wires Reviews
F A X ( 9 1 5 ) 8 5 7 - 3 3 4 4Parts Included:1 - Ignition1 - Harness, PN 8860WARNING:During installation, disconnect the battery cables. When disconnecting the battery always remove the Negative cable first and install it last.Note:Solid Core spark plug wires cannot be used with the Street Fire Ignition.Note: The Street Fire Ignition cannot be used with distributorless ignition systems (DIS).GENERAL INFORMATIONBATTERYThe Street Fire Ignition Control will operate on any negative ground, 12 volt electrical system with a distributor. Itcan be used with 16 volt batteries and can withstand a momentary 24 volts in case of jump starts. The Ignitions willdeliver full voltage with a supply of 9 - 18 volts and will operate with a supply voltage as low as 7 volts.COILSThe Street Fire Ignition can be used with most stock coils and aftermarket coils designed to replace the stock coils.If you have any questions concerning coils, contact our Customer Service Department at (915) 855-7123.TACHOMETERSThe Street Fire Ignition features a Tach Output wire that provides a trigger signal for tachometers, a shift light or otheradd-on rpm activated devices.
The Tach Output produces a 12 volt square wave signal with a 24% duty cycle.Some vehicles with factory tachometers may require a Tach Adapter to operate with the ignition. For more informationon Tachometers and MSD Tach Adapters, see the Tachometer Section on page 9.If your GM vehicle has an inline filter it may cause the tach to drop to zero on acceleration. If this occurs, bypassthe filter.FOREIGN VEHICLESDue to the fuel injection systems, some foreign vehicles may require a special Tach/Fuel Injection Adapter with aStreet Fire ignition. See page 9 for wiring and Tach Adapter information.Note: Vehicles originally equipped with a CD ignition control cannot use the Street Fire Ignition.SPARK PLUGS AND WIRESSpark plug wires are very important to the operation of your ignition system. A good quality, helically wound wire andproper routing are required to get the best performance from your ignition, such as the Street Fire Wire.Note:Solid Core spark plug wires cannot be used with the Street Fire Ignition.SparkPlugs: Choosing the correct spark plug design and heat range is important when trying to get the bestperformance possible. It is recommended to follow the engine builder or manufacturer's specification for spark plugs.With that, you can then experiment with the plug gap to obtain the best performance.
Msd Spark Plug Wires
The gap of the plugs can beopened in 0.005' increments, then tested until the best performance is obtained.MISCELLANEOUS INFORMATIONSealing: Do not attempt to seal the ignition. All of the circuits of the Street Fire ignition receive a thick conformalcoating of Humi-Seal. Rubber plugs are supplied to protect the rpm dials.Welding: If you are welding on your vehicle, to avoid the chance of damage, always disconnect both Heavy Powercables of the ignition (You should also disconnect the tach ground wire).1 - 18' Ground Wire1 - 100V/1A Diode4 - Mounting ScrewsStreet Fire CDIPN 5520ONLINEPRODUCTREGISTRATION:RegisteryourMSDproductonlineandyou’llbeenteredinourmonthly8.5mmSuperConductorSparkPlugWiregive-away!RegisteringyourproductwillhelpifthereiseverawarrantyissuewithyourproductandhelpstheMSDR&Dteamcreatenewproductsthatyouaskfor!Gotowww.msdignition.com/registration.
